The PathWave development team is pleased to announce the availability of Model Builder (MBP) 2020 Uodate 2.1. This release adds adds support for BSIM-IMG 102.9.4, BSIM-BULK 107, and BSIM-CMG 101.1 standard model versions, upgrades Java to JDK 8 and includes various bug fixes.
PathWave Model Builder (MBP) 2020 Update 2.1 Release Notes
MBP 2020 Update 2.1 is a minor update release and is a full installer (base release not required).
New Features and Enhancements
– Upgraded the default Java version to JDK 8 Update 202.
– Added new model BSIM-CMG 111.1.0
– Added new model BSIM-IMG 102.9.4
– Added new model BSIM-BULK 107.0.0
– Supports HiSIM_HV 2.4 with COSUBNODE=1
– Fixed the issue of IMV constants that can only be extracted from first loaded device data.
– Fixed the issue of parsing expression without single quotes for HSPICE.
– Fixed the issue that PathWave Model Builder (MBP) cannot work when subckt model and compact model have the same name.
PathWave Model Builder is a one-stop solution that provides both automation and flexibility for high-volume model generation. The software includes automated extraction packages for industry standard models as well as an open interface for modeling strategy customization. Turnkey solutions are also provided for the advanced statistical and mismatch model extraction, layout proximity effects (LPE) modeling, static random access memory (SRAM) cell modeling, HVMOS modeling, scalable Inductor modeling and corner library generation.
PathWave Model Builder is a complete modeling solution that integrates SPICE simulation, model parameter extraction and model library generation. The software supports the latest standard models including BSIM-BULK, BSIM-CMG and BSIM-IMG for logic, analog and RF designs. Besides compact models, PathWave Model Builder also supports the macro (subcircuit) model and Verilog-A model. It provides automatic extraction packages. The script environment enables extraction flow customization, device target definition and GUI operations. With its superior optimization technology and advanced features, PathWave Model Builder provides the most comprehensive, accurate and efficient modeling solutions, especially for silicon devices.
PathWave Model Builder 2020 adds the new UTSOI2 model extraction package, MOSRA-API based model extraction package, Lib Tweaking feature and other enhancements to improve modeling productivity and efficiency.
Keysight Technologies Inc. is the world’s leading electronic measurement company, transforming today’s measurement experience through innovations in wireless, modular, and software solutions. With its HP and Agilent legacy, Keysight delivers solutions in wireless communications, aerospace and defense and semiconductor markets with world-class platforms, software and consistent measurement science.
Product: Keysight Model Builder (MBP)
Version: 2020 Update 2.1
Supported Architectures: x64
Website Home Page : http://www.keysight.com
Languages Supported: english
System Requirements: Linux
Size: 1.0 Gb
