The most comprehensive course with 13.5 hours of real life structural examples under various loading conditions
What you’ll learn:
Various damage model such: Concrete damage plasticity (CDP), Johnson-cook, Johnson-Holmquist, Hasin damage model, ductile and shear damage model
Applying various loading condition (Tensile, compression, bending, high and low impacts, repetitive impact and cyclic loading)
Modelling concrete and steel column and beams
Reinforcing concrete beam and column with CFRP, Steel strips and bars and metal foam
Using XFEM method to to study crack growth
Abaqus Software (Version 6.14.1 is used for this course)
Basic knowledge of Abaqus software
Civil or Mechanical engineering background
Welcome to the Structural Engineering Abaqus Tutorial, the only course you need to learn how to deal with real-life structural engineering examples. This course is specially designed for mechanical, civil engineering students who want to expand their finite element knowledge. This course will teach you the theory behind input parameters as well as modelling and analysing the results.
What you will get in this course:
**This Course is the divided into the 12 sections and in order to get the most advantage of it, we highly recommend you to follow the course in order as the basic terms have been only explained in the initial sections.
An overview of this tutorial.
This section aims to teach you how to analyse various concrete beams under the 3-point bending condition. First, we start modelling the concrete beam only using CDP material property for concrete class B50, then in each video in this section, we try to reinforce the concrete beam with different methods such steel bars and strips, CFRP and metal foam. There are two assignment videos in this section that will help you to test your newly learned skills.
In addition, this section provides you with some background information about the concrete damaged plasticity (CDP), Hashin damage criterial for composite material and metal foam input parameters. It is highly recommended to watch all these videos and make sure that you understand the theory behind input parameters.
This section aims to teach you how to analyse various concrete column under compressive loading. In this section, similar to the previous section, we start modelling concrete only then we reinforce the column using the combination of the CFRP laminate and Steel bars and strips.
This section consisted of two simulations, in the first simulations, we apply load to the concrete column without any reinforcement to have some damage (around 0.05%) on our column then the load will be removed, and CFRP layers will be used in the damaged area to increase the strength of the column and then the load will be applied again.
This section aims to teach you how to model the combination of the concrete beam and column under cyclic loading.
In this section, you will learn how to apply tensile loading on various engineering application. This section consists of four examples: Concrete specimen, Aluminium specimen and single lap bolted joints under tensile loading and adaptive mesh. In addition, you will become familiar with ductile and shear damage theory in this section
In this section, you will learn how to apply impact loading on the concrete plate using the rigid and non-rigid projectile. In addition, you will learn how to import damage criteria for concrete using .inp and keyword section by importing 32 required parameters. This section consists of three examples as follow: Concrete block under impact loading using rigid projectile (Example-1), Concrete block with two metal sheet reinforcement under impact loading using steel projectile (Example-2), Crushable foam under impact loading using rigid projectile (Example-3)
In this section, you will learn how to consider the thermal behaviour of the material under impact loading and how these properties could affect the results.
In this section, you will learn how to perform a low-velocity impact simulation with fun example by simulating the phone drop from the height of the 5 meters.
In this section, you will learn how to perform repetitive impact loading on the metal beam using Johnson-cook damage model.
In this section, you will learn how to use the XFEM method to study the crack growth in a concrete beam under 3-point and 4 point bending condition using 2D and 3D examples.
This section has some background information about all the damage model used in this course.
I hope you all enjoy these tutorials. Please send me a message if you think anything can improve the quality of this course as I am updating the course regularly.
**This course is only intended for Serious Students. A lot of efforts have been done to provide a practical understanding of the Software, theory and analysis which is not available anywhere on the internet.
** Abaqus version 6.14.1 is used for this course, therefore in order to open files in the recourses section, you should have this version or any later version. However, you can still use the older version to do this tutorial.
** These course examples are not intended to apply to any particular situation. Students are cautioned to satisfy themselves as to the accuracy and results of their analyses. The author shall not be responsible for the consequences of any errors or mistake that may appear in this course.
** All rights reserved, Any unauthorised broadcasting, public performance, copying or re-recording will constitute an infringement of copyright.
Who this course is for
Civil or mechanical engineering students who would like to broaden their knowledge with real life examples
