PathWave Advanced Design System (ADS) 2024
Advanced Design System (ADS) 2024是一款由Keysight最新推出的先进设计系统(ADS),是领先的电子设计自动化软件,适用于射频、微波和信号完整性应用。


PathWave Advanced Design System (ADS) 2024 | 7.2 Gb

Keysight Technologies, Inc. introduces PathWave Advanced Design System (ADS) 2024, an electronic design automation (EDA) software suite giving chip designers new millimeter wave (mmWave) and subterahertz (sub-THz) frequency capabilities that accelerate 5G mmWave product design and anticipate requirements for 6G wireless communications development.

Developers of 5G and non-terrestrial network components are creating next-generation radio front-end modules using mmWave frequency bands that present significant design and simulation challenges. These frequencies are prone to signal loss due to propagation characteristics, atmospheric attenuation, complex packaging issues, and noise and dynamic range problems. Designing for 6G poses even greater challenges with sub-THz signals operating at higher frequencies.

Monolithic microwave integrated circuits (MMIC) and module designers are combining multiple semiconductor and III-V processes at mmWave frequencies, which requires multiple die assembly, module level interconnection, and power considerations. mmWave power amplifiers are built separately from the rest of the design to mitigate heat, yield, and semiconductor performance issues. In addition, power amplifiers developed in gallium nitride processes handle higher current densities than silicon.

New semiconductor packaging techniques, such as flip chip bonding, achieve higher densities and performance. These packages also require co-design across multiple technologies and processes because they concentrate challenges with internal crosstalk, electromagnetic interference (EMI), stability, and operating temperature.

The latest version of Keysight’s industry-leading radio frequency and microwave (RF/uW) design software suite addresses these development pain points with algorithm, layout, electro-thermal, and workflow automation enhancements.

New PathWave ADS 2024 design capabilities include:

Faster second-generation 3D-EM and 3D-Planar meshing and solvers – Delivers algorithm enhancements taking superior advantage of domain knowledge about microwave structures and processes. Mesh optimization and layout and connectivity improvements reduce problem sizes for faster simulations. Solver enhancements also speed simulation by up to 10 times and require less specialized user expertise over a wider range of problems, including mmWave design at automotive radar frequencies of 79GHz. Open workflows save database management and reduce overhead from iterative, manual setup.
Advanced layout and verification features – Enables design sign-off directly from ADS for LVS, LVL, DRC, and ERC for MMICs, as well as streamline productivity for module and multi-technology assembly. Wavetek is the latest foundry to fully support ADS for an end-to-end workflow.
Electrothermal enhancements accelerate validation – Drives higher reliability and higher operating performance with validation of dynamic device operating temperatures under different bias and waveform conditions. Supports high-performance compute acceleration and up to 100 times transient speed-up using W3051E Electrothermal Dynamic Re-use, enabling higher test plan coverage and earlier insights in the design phase.
Custom workflow support with expanded Python APIs – Increases flexibility and scalability. A load-pull data import utility, ANN modeling, and Python automation scripting for 5G power amplifier designers unlock new application potential to create targeted personalities of ADS.

Keysight’s PathWave, an open, scalable, and predictive software platform, offers fast and efficient data processing, sharing and analysis at every stage in the product development workflow. Combining design software, instrument control and application-specific test software, it enables engineers to address increasing design, test, and measurement complexity and develop optimal electronic products.
PathWave Advanced Design System (ADS) is the world’s leading electronic design automation software for RF, microwave, and high-speed digital applications. ADS pioneers the most innovative and powerful integrated circuit-3DEM-thermal simulation technologies used by leading companies in the wireless, high-speed networking, defense-aerospace, automotive and alternative energy industries. For 5G, IoT, multi-gigabit data link, radar, satellite and high-speed switched mode power supply designs, ADS provides an integrated simulation and verification environment to design high-performance hardware compliant with the latest wireless, high speed digital and military standards.
PathWave Advanced Design System (ADS) 2024 accelerates millimeter wave (mmW) monolithic microwave integrated circuit (MMIC) and module design by providing faster next-generation electromagnetic solvers, 10-100 times faster electro-thermal simulations, and expanded Python APIs for component designers working on 5G and 6G research applications.

Keysight shows some of the upcoming features of PathWave ADS 2024 at IMS 2023 in San Diego.
Keysight Technologies Inc. is the world’s leading electronic measurement company, transforming today’s measurement experience through innovations in wireless, modular, and software solutions. With its HP and Agilent legacy, Keysight delivers solutions in wireless communications, aerospace and defense and semiconductor markets with world-class platforms, software and consistent measurement science. The company’s nearly 10,500 employees serve customers in more than 100 countries.

PathWave Advanced Design System (ADS) 2024
Owner: Keysight Technologies Inc.
Product Name: PathWave Advanced Design System (ADS)
Version: 2024
Supported Architectures: x64
Website Home Page : http://www.keysight.com
Languages Supported: english
System Requirements: Windows & Linux *
Size: 7.2 Gb


Password/解压密码www.tbtos.com
