Altair Embed 特征
为涉及规模可变、定点操作的动态系统生成高效、紧凑的 ANSI C 代码。调整参数并监视实时数据。
无需手动编程。自动将框图和状态图转换为单片机 (MCU) 硬件可用代码。
支持常见的目标 MCU 硬件
包括多种来自德州仪器 (TI) 的工业级强大设备以及常见的 Arduino 和 Raspberry Pi 设备。
交互式硬件在环 (HIL) 测试
在位于主计算机上的 Altair Embed 内运行您的对象模型，在目标 MCU 上实时运行您的控制算法，并通过 HOTLink 进行通信。
File Size: 1.9 GB
Altair Embed™ software is a proven tool for developing embedded systems, by automatically generating code from block diagram models and transferring to popular controller hardware. Once you have a working simulation based on a system diagram, automatically generate the associated code for your hardware controller. You can also readily test your design using Hardware-in-the-Loop (HIL).
Why Altair Embed
From Diagram to Code, Simply
Avoid the tedium (and possible errors) associated with manually writing code for your embedded systems. Instead, automatically generate code directly from your system diagram.
The auto-generated code runs rapidly and produces high-quality results – no need to hand-code in order to speed up the execution of your code.
Robust, Reliable Process
While the auto-generated code is human-readable, there is no need to edit it or tweak it manually, because the automated process is dependable – it just works.
Tailored for Embedded System Development
Generate efficient and compact ANSI C code for dynamic systems involving scaled, fixed-point operations. Tune parameters and monitor real-time data.
Block Diagrams & State Diagrams
Simulate dynamic systems including continuous or discrete-time behaviors as well as event-based behaviors.
No manual coding required. Automatically converts your block diagrams and state diagrams to microcontroller unit (MCU) hardware-ready code.
Support for Popular Target MCU Hardware
Including many industrial-strength devices from Texas Instruments (TI) as well as popular Arduino and Raspberry Pi devices.
Interactive Hardware-in-the-Loop (HIL) Testing
Run your plant model in Altair Embed on the host computer while your control algorithm runs in real-time on the target MCU, communicating via a HOTLink.
Add-ons for Digital Power and Communications
Simulate and generate code for power supply and digital power components & controls. Model end-to-end analog, digital, and mixed-mode communication systems.
