Siemens Simcenter FloEFD 2606.0.0 v7194 Standalone x64

Simcenter FLOEFD 是一款独立CFD 软件，不需要预先安装CAx系统，具有多物理场功能，适用于设计师和分析师。该软件通过在开发设计早期进行流体流动仿真和热分析，并使用原生 CAD 几何体，可将开发时间比普通 CFD 方法缩短多达 65-75%。

前期 CFD 仿真可缩短开发周期
Simcenter FLOEFD 使设计工程师能够在设计流程的前期进行仿真，此时识别和修复问题或探索改进更具成本效益。它集成在 CAD 中，可将生产率提高 2 到 40 倍。

运用对设计师友好的直观 CFD 界面
通过 Simcenter FLOEFD 嵌入的 CAD 界面、引导式仿真设置和执行、智能自动化技术以及直观的结果查看方式，方便设计工程师进行仿真。他们能够尽早探索设计性能，无需克服传统障碍即可做出明智决策。

直接对原生 CAD 几何体执行 CFD，并消除 CFD 开销
消除工具之间几何体转换的延迟，并克服为 CFD 分析准备 CAD 几何体的复杂性。Simcenter FLOEFD 直接使用原生几何体：因此，当您探索性能或评估对模型做出的更改时，CAD 模型会同步更改。

它在强大的自动网格划分和独特的 SmartCell 技术方面具有明显优势，可以处理任何质量的 CAD 几何体。这些优势有助于处理装配体中的窄小间隙和表面不一致性，而传统的 CFD 工具通常会导致修复延迟过长。此外还有智能自动化预处理，如 CAD 几何体的自动密封和渗漏识别。

使用仿真驱动型设计 – 探索、比较和优化
利用参数化研究和设计探索功能，在可用时间内评估更多设计方案。评估“假设”场景，确保产品在不同条件下的性能和可靠性。

使用该软件，只需点击几下，即可轻松通过 CFD 可视化结果图、绘图和表格结果对设计进行并排比较，并生成报告。通过仿真优化设计后，您可以直接将 CAD 模型传递给其他工程设计部门。

File Size: 7.9 GB

FloEFD Standalone version does not require pre-installed CAD systems, is based on advanced Computational Fluid Dynamics (CFD) technology and allows you to analyze a wide range of complex problems,

including
• Analysis of hydro-aerodynamics and heat transfer of two- and three-dimensional models
• Analysis of external and internal flow flows
• Analysis of steady and unsteady flow
• Flow of incompressible liquid and compressible gas, including combustible mixtures, at subsonic, transonic, supersonic and hypersonic flow regimes
• Condensation of water vapor
• Calculation of relative humidity in gas flows
• Flow in non-Newtonian fluids (laminar flow only)
• Flow in compressible fluid (fluid density depends on pressure)
• Flows in real gases
• Analysis of laminar, turbulent and unsteady flows
• Analysis of vortex flows and fans
• Analysis of flows with solid inclusions
• Analysis of heat transfer inside and between fluids and solids
• Analysis of heat transfer inside solids in the absence of a flow
• Calculation of thermal contact resistance
• Calculation of electrical contact resistance
• Thermoelectric coolers
• Radiative heat transfer
• Joule heating
• Flows with gravity effects (also known as the buoyancy effect)
• Porous media
• Heat pipes
• Heat transfer in printed circuit boards
• Heat transfer in perforated plates
• Aerosol flow
• Accounting for the roughness of bodies during flow •
Accounting for tangential motion of walls (displacement and rotation)
• Flow in rotating devices
• Cavitation in liquid flows
• Combustion in gas mixtures

What’s New
official site does not provide any info about changes in this version.

System requirements
minimal
Operating System: Windows 10 Pro (64-bit)
Processor: 4-core Intel/AMD (x86-64)
Memory (RAM): 16 GB
Graphics Card: OpenGL 3.3 compatible

recommended
Operating System: Windows 11 Pro/Enterprise (64-bit)
Processor: 8+ cores (Intel Core i9/Xeon or AMD Ryzen 9/Threadripper)
Memory (RAM): 32 GB to 64 GB+ (High RAM is critical for complex meshes)
Graphics Card: NVIDIA RTX / Quadro or AMD Radeon Pro

– Localized languages: French, German, Japanese, Korean, Simplified Chinese, Russian
