CGTech VERICUT 7.2.3 数控仿真

CAX/EDA dsgsd 239浏览 0评论


VERICUT软件可以模拟CNC加工,用来检测错误、潜在的碰撞以及低效的加工区域。在把程序传入机床之前,VERICUT可以让数控编程人员发现并纠正错误,这样可以避免工件的试切。VERICUT也可以优化数控程序的切削速度,获得更高的加工效率——甚至在高速铣削上!

Vericut 7.0亦重新设计了刀具管理器,使Vericut的程式优化模组——OptiPath变得更容易使用。刀具优化库将设置在刀具管理器 ,这样不仅简化了使用过程,而且不同的刀具可以参考同一个优化库。新的刀具装配向导允许用户在一个简单的用户介面里,通过对话方块的形式创建一把新铣刀。如果用户已经在其他刀具库 建立了一把刀,用户可以参考或复制整个刀具,或刀片、刀柄,建立新的刀具。

Vericut模型输出功能在7.0里得到了加强,能够输出CATIA V5、ACIS SAT和STEP模型,模型输出能够在Vericut类比NC程式的任何过程中创建CAD模型。这个模型包含了各种加工特徵,如:孔、倒角、圆弧、凹槽、凸台,这些特徵非常精确,和实际加工特徵一样。在Vericut 6.2里面,模型输出可以输出能够产生的特徵,单独的不能生成的特徵或不好的特徵(如球头刀生成的“凹坑”)可以输出综合特徵。其他的增强功能使模型的表面和边界更光顺。输出的文件使用NURBS修整曲线,减小了文件的大小。




CGTech VERICUT 7.2.3 | 1.7 Gb

VERICUT software is used to simulate CNC machining in order to detect errors, potential collisions, or areas of inefficiency. VERICUT enables NC programmers to correct errors before the program is ever loaded on the CNC machine, thereby eliminating manual prove-outs. VERICUT also optimizes NC program cutting speeds for more efficient machining.

CGTech VERICUT 7.2.3CGTech VERICUT 7.2.3

New Features in Version 7.2.3:

– Drag/drop files from Windows into the Project Tree for quick setup. The file extension helps determine where.
– Constant gouge check simulation with very large design models is now 2-5x faster.
– Automatically save a Reviewer file during the simulation session. The VERICUT Reviewer incorporates all the functionality of NC Review mode in a stand-alone viewer that does not require a license.
– Measure tool assembly components in the tool manager.
– Many CAD/CAM interface improvements have been implemented.
– SpacePilot Mouse/Navigator motion is improved.

VERICUT 7.2.3 Release notes: this

CGTech VERICUT 7.2.3CGTech VERICUT 7.2.3

About CGTech

Headquartered in Irvine, California CGTech specializes in numerical control (NC/CNC) simulation, verification, optimization and analysis software technology for manufacturing. Since 1988 CGTech’s product, VERICUT software, has become the industry standard for simulating CNC machining in order to detect errors, potential collisions or areas of inefficiency. With offices worldwide, VERICUT software is used by companies of all sizes, universities and government agencies.

Name: CGTech Vericut
Version: 7.2.3
Home: http://cgtech.com/
Interface: english
OS: Windows XP / Vista / Seven
Size: 1.7 Gb

Bonus: Model interface 7.2.3




1. Install Vericut 7.2.3
2. Put cgtech.lf to “C:\Program Files\CGTech\VERICUT 7.2.3\windows\license” or “C:\Program Files\CGTech\VERICUT 7.2.3\windows64\license”
3. Setup/start license service
4. If you need Drilling&Fastening then unpack vdaf723.rar over Vericut installed.

NB: Once a year, starting from 2014.01.01 you have to edit cgtech.lf according to instructions inside it.



Download uploaded
http://ul.to/6svqxdon

Download 百度云:链接:http://pan.baidu.com/share/link?shareid=1525747423&uk=926257522 密码:q2dh
