CADintosh X 8.8.8 MacOS

CADintosh 是Mac os平台上的一款帮助用户绘制CAD图的Mac平面设计软件，为技术绘图员和设计师提供了高性能的2D CAD程序。

File size: 70 MB

CADintosh is a High Performance 2D CAD program for Technical Draftsmen and Designers.
You will benefit from professional and well thought-out features for all your design requirements.

Workflow improvement and usability advantages
– Single window interface (quick access to all features without any additional tool windows)
– Retina display support
– The number of elements is only limited by your available memory
– Pre-settings are saved for each drawing

Key features: Lines and tools
– 8 pens with freely definable line widths and line colors
– 6 line types: full line, dotted line, chain line, dotted line with two dots, zigzag line, short dotted line
– Individual mode: line widths from 0.0 to 99.99 mm, and each element can be designated a different color and width (not compatible to HPGL)
– Functions available for lines, circles, dimensioning, hatching, X lines, etc.

Support for groups and layers
– 32,000 groups
– 1,024 layers
– simple layer management

Compatibility
– Import and export of DXF, HPGL, IGES and PDF
– Unicode support
– Support for symbol libraries for the import and export of symbols
– Alternative units, e.g. for inches
– Runs natively in Mac OS X

Supported Operation Systems
macOS 10.11 or later
