A lot of time has passed since the release of the first version of IDEA StatiCa Connection in 2014. At that time, the developers of the program presented a completely new approach to the calculation and design of joints of steel structures. The program is based on a unique tool – the Component Finite Element Method (KEME), thanks to which such a rapid growth in the popularity of IDEA StatiCa has become possible as the software that has become today the leader in the design and calculation of steel structure units. IDEA StatiCa was able to solve many problems associated with taking into account local effects arising from the calculation, and organically fit into the modern concept of BIM-design.
Based on the feedback of more than 2,000 customers worldwide, IDEA RS is constantly expanding the functionality of its software products, which allows you to significantly speed up the work process and improve the integration of IDEA StatiCa with third-party calculation and design applications (Tekla Structures, SAP2000, ETABS, Advance Steel, etc.)
The release of version 10 is very promising, as it aims to resolve a serious technical issue – calculation of nodes of steel structures for seismic effects. And this question should be solved not only for simple and template nodes, but for constructions with any topology loaded with arbitrary efforts. In this case, the process should take a few minutes. The new IDEA StatiCa Connection calculation mode for seismic effects was created precisely to eliminate the described difficulties that arise in every project around the world. Reliable and fast calculation of steel structures,
IDEA StatiCa 10 implements inspections of steel structure joints according to SP 16.13330.2017. Now you can check the ordinary and prestressed bolts and welds in accordance with Russian standards. Also, the new version adds design checks according to SP 16.13330.2017 for bolts and welds.
Russian assortments and steel grades have been added to the database of materials and sections according to tables B.3, B.4 and B.5 of the corresponding annex SP 16.13330.2017.
The new Capacity Design calculation mode replaces the current Member Capacity mode. Due to the high level of adaptability, the new calculation allows you to check nodes for any seismic area. In Capacity Design mode, a new assembly operation, Dissipative Element, is used, which defines the plates or elements to which the reinforcement coefficients will be assigned. The strain hardening coefficient can also be set here. The appearance of a plastic hinge can be described and analyzed. This calculation mode is available for all available standards (SP, EN, AISC, CISC, AS).
In IDEA StatiCa 10, a check of pipes for local deformations that often occur at their joints with each other has been added.
Close attention was paid to improving the work of BIM-bundles and the procedure for recognizing welds when importing from third-party applications. Now, in version 10.0, welds in the frame nodes that coincide in direction with the axis of the beam are transferred correctly.
Steel Member is a completely new application, which is also based on KMKE, as in IDEA StatiCa Connection, only it is used here on a large scale – with respect to whole beams, columns and frames
The program focuses on issues of linear stability and longitudinal-transverse bending of elements, taking into account the influence of real conditions of fastening of elements and their support. Engineers will be able to calculate stability in FEM programs in the usual way. IDEA StatiCa Steel Member allows for a more accurate assessment of complex and non-standard elements.
The IDEA StatiCa 10 software package includes a beta version of IDEA StatiCa Steel Member for the calculation and design of core elements (beams, columns, struts, etc.) to demonstrate the capabilities of the application.
