JMAG Designer 12.0 X64

JMAG-Studio是由日本综合研究所（JRI）开发的功能齐全，应用广泛的电磁场分析软件。软件可以对各种电机及电磁设备进行精确的电磁场分析，为用户提供设计上帮助，降低用户产品的开发周期，取得竞争优势。

JMAG-Studio自从1983年商业化以来，在日本的市场占有率始终保持第一的位置。在日本电机领域分析了大量各种类型的电机，经历了时间和实践的检验。同时在每年至少一次的软件升级中不断吸收日本电机厂家的先进经验。平时加强与众多客户的紧密联系，通过定期的技术交流共同进步。目前JMAG-Studio的国内用户不断增加，在业界取得了较高的知名度。

 JMAG Designer 12.0 (64bit) | 1.9 Gb

This is the high-speed, high-precision FEA software tool at the core of JMAG. An intuitive interface and precise modeling technology with a wide variety of results displays are built in. Multifaceted evaluation of various design ideas is made possible by freely manipulating geometry, material properties, and drive conditions.

This report contains messages from the people in charge of developing the new functions in version 12:

– Simulation Engine
JMAG endeavors to provide fast and stable solvers and meshers. In Ver.12, we have released an expanded slide mesh that provides proper GPU support and mesh with a greater degree of freedom and precision.
– Physical Modeling
Detailed modeling is necessary to carry out accurate analyses, but there are limits to how much time can be spent on modeling. JMAG provides modeling functions that allow both high accuracy and high speed. Ver.12’s release includes support for magnetostriction, as well as eddy current loss calculation functionality for laminated steel sheet. It also supports coil end modeling functions and harmonic current input for calculation of stray load loss.
– Results Analysis
Designs become more reliable as simulation can be done with more combinations of design parameters. We are always working toward better functionality for analyzing results in JMAG, and in Ver.11, we improved its efficiency map and parametric analysis functions. For Ver.12, we have added optimization functions, evaluation of differences between results, and functions for harmonic analysis.
– Easier to Use
JMAG is a general-purpose simulation tool primarily for electromagnetic field analysis. It includes a large number of superior functions to enable better simulation. However, most designers who use JMAG need it for certain types of analysis.
Because of this, JMAG includes JMAG-Express, aimed particularly at motor designers. Ver.12 adds synchronous reluctance motor (SRM) support to the previously-supported permanent magnet synchronous motor (PMSM) and induction motor (IM).
We have also released JMAG-VTB Ver.2.0 with a new interface to be used as a dedicated system by users other than motor designers as well.

About JSOL Corporation

As information technology becomes increasingly important, what businesses need is a trustworthy and reliable IT partner.

Based on advanced technology and practical expertise, JSOL provides IT solutions tailored to customer needs in every area from IT consulting to system implementation and operation. We not only seek to gain a deep understanding of our customers’ business and help them to achieve success, but also strive to build strong, long-lasting partnerships.

As professionals who satisfy complex customer needs, our staff have the vision to understand the essence of the problems facing the customer and the flexible thinking that allows them to deliver solutions to those problems. Whether as individuals or as an organization, we strive at all times to earn the trust of our customers.

That is the essence of JSOL’ philosophy.

Name: JMAG Designer
Version: (64bit) 12.0
Home: www.jmag-international.com
Interface: english
OS: Windows XP / Vista / Seven
Size: 1.9 Gb
